L5027MG400E
L5027MG400E - obrazek 2
L5027MG400E - obrazek 3
L5027MG400E - obrazek 4

L5027MG400E

Sensor 2K
Image Sensor CMOS
Shutter Global
Resolution 2048 × 4
Line Rate 59 kHz(After compression the line frequency is 66k）
Bit Depth 12
Mono/Color Mono
Pixel Size 7 μm × 7 μm
Pixel 2048×4
S/N Ratio 39.6 db
Dynamic Range 65.5 db
Image Format Mono8/10/12/10P/12P
Binning Support
ROI Support
X Flip Support
Gain 1~32
Gamma From 0 to 4, support LUT
Exposure Time 8 μS~100 mS
Trigger Mode Software Trigger/Hardware Trigger/Free Run Mode
FPN Support
TDI Stages single_line, 2TDI, 4TDI
User Setting Support two sets of user-defined configurations
Image Buffer 64MB Image Cache, 64M Data Cache
Port GigE
GPIO Interface 12-pin Hirose interface for external power supply and external triggering; 2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output
Lens Mount C-Mount
Power Supply DC12-24V power supply
Power Consumption 4.6 W
Product Dimensions 29 mm × 44 mm × 57.5 mm (Not including rear case connector)
Net Weight 100 g
Storage Temperature -30℃~+80℃
Operating Temperature 0℃~+50℃
Dodaj do ofert
Kategoria: Znacznik: Marka:

Opis

  • The resolution is 2K, the pixel size is 7?m, and the maximum line frequency can reach 59K
  • High dynamic range, good signal-to-noise ratio, and excellent image quality
  • Support a variety of image data format output
  • Support 2TDI, 4TDI
  • Support multiple ROI, FPN correction
  • Support Gamma, LUT, automatic black level and other ISP functions
  • Support software trigger/hardware trigger/free run and other trigger modes
  • Compatible with GigE Vision V2.0 protocol and GenICam standard
  • Support DC12-24V wide voltage power supply

Dimensions

Downloads

iRAYPLE_GigE_Line_Scan_Camera_user_s_Manual_V3.0.0.pdf

Informacje dodatkowe

Binning

Support
Bit depth

12
Dynamic range

65.5 db
Exposure time

8 us~100 mS
Fpn

Support
Gain

1~32
Gamma

From 0 to 4，support LUT
Gpio interface
Image buffer

64MB Image Cache，64M Data Cache
Image format

Mono8/10/12/10P/12P
Image sensor

CMOS
Lens mount

C-mount
Line-rate

59 kHz(After compression the line frequency is 66k）
Pixel

2048×4
Pixel size

7 um x 7 um
Port

GigE
Power consumption

4.6 W
Power supply

DC12-24V power supply
Resolution

2048 x 4
Roi

Support
Sensor

2K
Shutter

Global
Storage temperature

-30℃~+80℃
Trigger mode

Software Trigger/Hardware Trigger/Free Run Mode
User setting

Support two sets of user-defined configurations
X flip

Support
Mono-color

Mono
S/n ratio

39.6 db
Tdi stages

single_line，2TDI，4TDI
