RT-TV-05M-800

RT-TV-05M-800

Specification Value
Magnification 0.500 (x)
Image circle diameter 8.9 (mm)
Max sensor size 1/1.8″
1/3″ 9.60 x 7.20 (mm x mm)
1/2.5″ 11.40 x 8.56 (mm x mm)
1/2″ 12.80 x 9.60 (mm x mm)
1/1.8″ 14.26 x 10.66 (mm x mm)
Working distance 800.0 (mm)
Working f/N 16.7
Distortion < 0.03 (%)
Depth of field 3.90 (mm)
Resolution 22.4 (μm)
Mount C
Phase adjustment Yes
Length 274.8 (mm)
Front diameter 58.0 (mm)
Mass 475 (g)
Dodaj do ofert
Kategoria: Znacznik: Marka:

Opis

  1. Working distance: distance between the front end of the mechanics and the object. Set this distance within ±3% of the nominal value for maximum resolution and minimum distortion.
  2. Working f-number (wf/N): the real f-number of a lens in operating conditions.
  3. Measured from the front end of the mechanics to the camera flange.

Informacje dodatkowe

Lens mount

C
Length

274.8 (mm)
Operation power source
Color
Accessory developer

Opto
Distortion

< 0.03 (%)
Front diameter

58.0 (mm)
Image circle diameter

8.9 (mm)
Resolution

22.4 (μm)
Mass

475 (g)
Phase adjustment

Yes
Depth of field

3.90 (mm)
Working f/N

16.7
Working distance

800.0 (mm)
Zoom ratio

0.500 (x)
Optmag

0.500 (x)
Sensor size
